Engenius - EWS7928P | 24-Port Managed Gigabit 185W PoE+ Switch

Delivery options
  • 1 Years warranty
  • Cash On Delivery Available
  • Shippment And Pickup


  • Power Source : 100 ~ 240VAC, 50-60Hz 4A
  • Brand: Engenius
  • EWS7928P Device: Weight: 7.9 Ibs (3.6 kg) Width: 17.32” (440 mm) Length: 10.23” (260 mm) Height: 1.73” (44 mm)
  • Humidity (Non-Condensing) : 5% – 95%
  • LED Indicators : Device: Power LED Fault LED PoE Max LED LAN Mode LED PoE Mode LED
  • LED Indicators: Reset Button Desktop/Wall Mount
  • Network Ports: 24 10/100/1000 Mbps Ports 4 10/100/1000 Mbps SFP Ports 1 RJ45 Console Port
  • Networking Device Type : Network Switch
  • Package Contents : (1) EWS7928P Switch (1) Power Cord (1) RJ45 Console Cable (1) Rack Mount Kit (1) Quick Installation Guide
  • PoE Budget : 185 W
  • PoE Capability : PoE Standard: Ports 1~24 Support IEEE 802.3at/af PoE Capable Ports: All Gigabit Ethernet Ports/Up to 30 W
  • Port Standards: 802.3 10Base-T Ethernet 802.3u 100Base-TX Ethernet 802.3ab 10000Base-T Ethernet 802.3x Full-Duplex Flow Control
  • Ports : Link/Activity/Speed (per Ethernet port) Link/Activity/Speed (per SFP slot)
  • Temperature Range : Operating: 32 to 122° F/0 to 50° C Storage: -4 to 158° F/-20 to 70 ° C


The EWS7928P Managed PoE+ 24 Port Gigabit Switch features simplified network configuration, monitoring, and management options along with an intuitive Web interface. Locally manage up to 50 EnSky APs and centrally manage wired and wireless networks via ezMaster. Power compatible PoE+ devices such as IP cameras, VoIP phones, and APs.

  • (24) 10/100/1000 Mbps Gigabit Ethernet PoE+ Ports; (4) SFP Ports
  • 19” Rackmount Supports 802.3af/at PoE & Total Budget of 185W
  • 4 Types of In-Switch Network Management Options
  • Network Troubleshooting, Monitoring & Email Alerts


  • Simple to Deploy, Use and Manage
    Centralized management, quick setup through a web-based user interface. Supports management of up to 50 Neutron Series Access Points. Lets IT managers keep track of, map out, and plan the placement of Neutron Series Access Points and Switches in the network with a visual view of the topology as well as tools to search for and find Neutron Series Access Points via their IP or MAC address. Also gives IT managers and network administrators the visibility they need to monitor, manage and quickly adjust the settings or performance of their network in real time. The feature rich interface displays usage reports for real time and historical client connectivity to each Neutron Series Access Point as well as traffic flow and load over both wired and wireless portions of the network.
  • PoE+ IEEE 802.3at/af Support
    Enables PoE devices like Access Points, Client Bridges, IP Cameras, VoIP telephones and others to be powered directly from the Switch over an Ethernet cable. Up to 30 Watts per port with a total PoE budget of 185 Watts
  • 4 Dual-Speed SFP Ports
    Includes 4 SFP ports to support transceivers for fiber cabling for connectivity to offices, buildings, or other parts of the network that exceed the distance capability of regular Ethernet.
  • Full-Featured Layer 2 Manageability
    VLAN, QoS, IGMP/MLD Snooping, STP/RSTP/MSTP, Link Aggregation Control Protocol (LACP), SNMP v1/v2c/v3, and more.
  • PoE Management
    The Switch’s User Interface allows IT managers the ability to allocate just the amount of wattage they need per port to power specific PoE client devices to conserve as much of their Neutron Series Switch’s total PoE budget as possible. Including more Neutron Series Switches to the network gives administrators the ability and versatility to substantially and rapidly scale their networks and to provide just the right Neutron Series Switch necessary to provide wireless connectivity or surveillance in a part of the network previously unserved.
  • AP Auto IP-Assignment
    Assign an IP address range for wireless clients connecting to the network
  • Advanced Wireless Settings for Neutron Series Access Points
    Supports Band Steering, Fast Handover and Guest Network features
  • Cluster Management
    Setup and assign Access Points in clusters within your network to manage the group of Access Points as a single wireless network instead of a series of separate devices.

Power & Connect Mutliple Devices

Utilize the Neutron Gigabit Managed PoE+ Switch to optimize the installation and power management of network devices such as access points, IP cameras, and VoIP phones. Provide 802.3at/af PoE+ power and data on all ports and regulate power budgets according to device requirements.

Power & Connect Mutliple Devices

High Performance Gigabit & Management Flexibility

Each of Neutron Gigabit Managed PoE+ Switch’s Gigabit Ethernet ports ensures seamless, high-speed access for networked devices while reducing bottlenecks that can interrupt critical communications. The Switch offers the deployment and management flexibility needed to support both wired and wireless networks efficiently.

Simplified Network Management & Visibility

Achieve network management, visibility and troubleshooting locally through the Switch’s onboard Web interface tools or remotely with ezMaster software. Its Network Topology view automatically maps the deployment, displaying device relationships across the infrastructure, and is useful for troubleshooting issues without manual tracking.

Wireless Device Management

Quickly discover, configure, and monitor Neutron EWS Access Points and manage up to 50 devices within the local subnet through the Switch’s built-in wireless network controller features.

Centrally Manage the Wired & Wireless Network

Remotely manage Neutron EWS Access Points, Switches, and IP Cameras through ezMaster Network Management Software. Centrally manage hundreds of EWS devices across the network regardless of its size or location without licensing or subscription fees.

VLAN/Voice & Quality of Service

Segment the network by departments or traffic types for increased performance and security with 802.1Q VLAN. Prioritize compliant VoIP and video traffic using 802.1p Class of Service (CoS) ensuring high bandwidth, and time-sensitive data is forwarded immediately for clear, smooth voice and video delivery across the network.

Secure Guest Networks

Establish secure Guest Network VLANs that blocks access to central computers and limits Internet resources for visitors. Safeguard the network from sophisticated Trojans and malware that can use guests’ mobile devices to attack it.
